Marine Flush Conversion Kit Jabsco HoseCoil Washdown Systems

A range of high quality deckwash hose storage systems from HoseCoil USA. The self coiling hoses are constructed from strong and highly fl exible blue polyether material – see previous pages for all the features of HoseCoil hose. All enclosure kits are made from highly durable UV stabilised materials and come with either a quality hose nozzle or a brass trigger spray gun for effective anchor and deck washdown.

Horizontal Mount Enclosure

Horizontally mounted enclosure in durable UV resistant materials. Can be mounted in a convenient location while still remaining out of the way and allowing easy use of the washdown hose & system. Supplied with with 7.6 metres (25 foot) of coiled washdown hose and variable fl ow hose spray nozzle. Also includes 1.5 metres (5 foot) of water inlet hose.

Supplied in colour clamshell open display packaging.

515mm length x 240mm height x 125mm depth

Flush Mount Hatch Enclosure

The HoseCoil hatch enclosure mounts fl ush into the deck or bulkhead. The twist lock lid has a waterproof O ring seal and completely removes from the enclosure for easy access to the hose.

The hatch is fully enclosed underneath in a clear plastic casing for easy inspection and is fitted with a hose tail for water drainage and a brass water inlet fitting.

The kit includes 4.5 metres (15 foot) of HoseCoil hose and a variable fl ow trigger nozzle. Supplied in colour clamshell retail packaging.

200mm diameter x 300mm deep. Requires a 170mm cutout hole and 330mm clearance below deck.
