Jabsco Lite-Flush Electric Toilets

Lightweight space-saving contempory design electric toilet to give your bathroom a modern stylish look. This toilet is lighter duty than the “Deluxe Silent Flush” models on previous page and is for use on recreational craft only – not for use on commercial craft and hire boats Etc.

The toilet has a high quality plastic outer casing with a ceramic inner bowl. The innovative design offers low power usage and low water consumption to maximize holding tank capacity.

They have an extremely quiet, virtually silent, integral raw water rinse pump and a non-clogging, macerating, waste pump system housed wholly within the toilet, to save space on board.

The lite-flush has the same mounting footprint, fixing points and hose attachment as the Jabsco manual toilet for ease of installation and retro-fit.

2 models are available

• A BASE FOOTSWITCH MODEL – left or right fitting. Uses an integral footswitch to control the operation of the toilet
• CONTROL PANEL MODEL – uses a wall mounted multi-function one touch control pad for fill or flush

Some of the features of the Lite-Flush toilet are

• Lightweight (11 Kg) and compact, space-saving stylish design
• Efficient Jabsco technology gives virtually SILENT operation
• Efficient, very quiet, Jabsco electric diaphragm water intake pump
• Non-clogging large bore centrifugal flush pump macerates waste
• Can use as little as 1.2 liters of water per flush
• Crevice-free contours for hygiene and easier cleaning
• Slow-close seat and lid won’t bang shut
• Anti-odour water lock in pump housing
• Low power consumption – less than 1 amp/hour per day
• Easy retro-fi t if replacing a Jabsco manual toilet
• Toilet discharges up to 1.5 meters above the base of the toilet
• Water intake pump self primes up to 2.4 meters
• Easy access to flush and rinse pumps for servicing
• 3/4″ 19mm water inlet – 1 1/2″ 38mm discharge outlet
• Compact size : 373mm height, 402mm depth, 342mm / 401mm width

Lite-Flush Toilet With Wall Mount Control Panel

Includes complete Lite-flush electric toilet with a wall mounted control panel with 3 meters link cable, fitted quick connector and heat shrink seal. The control panel has easy one-touch setting.

Lite-Flush Toilet With Foot Switch Control

Includes complete Lite-Flush electric toilet with an integral foot operated switch. Simply press down once to add water to the bowl and press again to flush and discharge. 12 volt only.
